Highlights
View Details- Smart-UPS is perfect for servers, voice/data networks, medical labs and light industrial applications
- Load capacity: 1 - 20 kVA
- Dimensions: 5.1"H x 17"W x 28.32"D
APC Smart-UPS SRT 5000VA RM 5000VA UPS, 4-Outlets, Black (SRT5KRMXLT)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
The APC SRT5KRMXLT 208 V rack mountable Smart-UPS with 1 to 20 kVA load capacity, is perfect for servers, voice/data networks, medical labs and light industrial applications. With the included PowerChute management software, this Smart-UPS offers unattended graceful shutdown of network operating systems. The Smart-UPS maximizes the battery performance, life and reliability with the intelligent, precision charging management. It features an LCD graphics display that displays text and mimics diagrams.
- Smart-UPS is perfect for servers, voice/data networks, medical labs and light industrial applications
- Load capacity: 1 - 20 kVA
- Dimensions: 5.1"H x 17"W x 28.32"D
- Offers 1.5 hrs. recharge time with 840 VAh capacity
- Output voltage: 208 V
- LCD graphics display for displaying text and mimic diagrams as well as system parameters
- 3U Rack mountable
- Output power capacity: 4.25 kW
- Interface/ports: RJ-45 10/100 Base-T, RJ-45 serial, smart-slot, USB, Output connections: (2) NEMA L6-20R, (2) NEMA L6-30R
- Provides IP20 protection
- Cord length: 10'
- Load crest factor: 3:1
- Input voltage: 160 - 275 V, 100 - 275 V (half load)
- Battery type: Sealed lead-acid
- Surge energy rating: 480 J
- Multi-function LCD status and control console, audible and visible alarms prioritized by severity
- Temperature: 0 - 40 deg C (operating), -15 to 45 deg C (storage), 0 - 95% humidity, 10000' elevation operating, 50000' storage
- Meets CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, NOM, UL 1778, RoHS and REACH certifications or standards
- Weight: 123 lbs.
- Comes with 3 years repair or replace warranty (excluding battery) and 2 years warranty for battery
| Manufacturer # | |
| Battery Backup Connectivity | USB |
| Battery Backup Lcd Display | Yes |
| Battery Backup Run Time | less than 10 minutes |
| Battery Backup or Ups Device Type | UPS |
| Battery Backup or Ups Form Factor | Rackmount |
| Brand Name | APC |
| Charge Time (hours) | 1.5 |
| Compliance Standards | RoHS, IP20, UL 1778, CSA C22.2 No. 107.3, REACH, FCC Part 15 A |
| Connector, Port or Interface Type(s) | RJ-45 10/100 Base-T, RJ-45 serial, smart-slot, USB, Outputs: (2) NEMA L6-20R, (2) NEMA L6-30R |
| Cord Length (ft.) | 10 |
| Depth in Inches | 28.3 |
| Height in Inches | 5.1 |
| Input Voltage | 208/240 |
| Joule Rating | 480 |
| Mountable | Mountable |
| Operating Temperature (degrees) | 32 - 104 deg F |
| Outlet Count | 4 |
| Output Power Capacity (w) | 4250 |
| Output Voltage | 208 VAC |
| Power Capacity (va) | 5000 |
| Rack Units | 3U |
| Series or Collection | Smart-UPS SRT 5000VA RM |
| True Color | Black |
| Types of Battery | Lead Acid Battery |
| Usb Connectivity | USB Connection |
| Va Rating | More than 3000 |
| Warranty Information | 3 Year |
| Weight (lbs.) | 123 |
| Width in Inches | 17 |
Details
The APC SRT5KRMXLT 208 V rack mountable Smart-UPS with 1 to 20 kVA load capacity, is perfect for servers, voice/data networks, medical labs and light industrial applications. With the included PowerChute management software, this Smart-UPS offers unattended graceful shutdown of network operating systems. The Smart-UPS maximizes the battery performance, life and reliability with the intelligent, precision charging management. It features an LCD graphics display that displays text and mimics diagrams.
- Smart-UPS is perfect for servers, voice/data networks, medical labs and light industrial applications
- Load capacity: 1 - 20 kVA
- Dimensions: 5.1"H x 17"W x 28.32"D
- Offers 1.5 hrs. recharge time with 840 VAh capacity
- Output voltage: 208 V
- LCD graphics display for displaying text and mimic diagrams as well as system parameters
- 3U Rack mountable
- Output power capacity: 4.25 kW
- Interface/ports: RJ-45 10/100 Base-T, RJ-45 serial, smart-slot, USB, Output connections: (2) NEMA L6-20R, (2) NEMA L6-30R
- Provides IP20 protection
- Cord length: 10'
- Load crest factor: 3:1
- Input voltage: 160 - 275 V, 100 - 275 V (half load)
- Battery type: Sealed lead-acid
- Surge energy rating: 480 J
- Multi-function LCD status and control console, audible and visible alarms prioritized by severity
- Temperature: 0 - 40 deg C (operating), -15 to 45 deg C (storage), 0 - 95% humidity, 10000' elevation operating, 50000' storage
- Meets CSA C22.2 No.107.3-05, ENERGY STAR (USA), FCC Part 15 Class A, NOM, UL 1778, RoHS and REACH certifications or standards
- Weight: 123 lbs.
- Comes with 3 years repair or replace warranty (excluding battery) and 2 years warranty for battery
| Attribute Name | Attribute Value |
|---|
