Highlights
View Details- This access point provides high performance and cost-effective Wi-Fi 6 (802.11ax) for hospitality, branch, and teleworker deployments
- With a wireless aggregate data rate of up to 1.5Gbps, delivers the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike
- Contains three Ethernet wired network ports (RJ45) with auto-sensing link speed (10/100/1000BASE-T) and MDI/MDX
Aruba 503H 1500 Dual Band Access Point, White (R3V38A)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
These economical Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing mobile, cloud and IoT requirements. With a wireless aggregate data rate of up to 1.5 Gbps and gigabit local wired ports, they deliver the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike. The Aruba 503H series APs are designed to optimize user experience by maximizing Wi-Fi efficiency and dramatically reducing airtime contention between clients. Features include Orthogonal frequency-division multiple access (OFDMA), and cellular optimization. With up to two spatial streams (2SS) and 80MHz channel bandwidth, the 503H series provides groundbreaking wireless capabilities for budget-conscious deployments
- This access point provides high performance and cost-effective Wi-Fi 6 (802.11ax) for hospitality, branch, and teleworker deployments
- With a wireless aggregate data rate of up to 1.5Gbps, delivers the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike
- Contains three Ethernet wired network ports (RJ45) with auto-sensing link speed (10/100/1000BASE-T) and MDI/MDX
- Dimensions: 5.9"H x 3.39"W x 1.57"D
- Maximum power consumption: 10W DC powered, 11.4W POE powered
- Two integrated semi-directional antennas for 2 x 2 MIMO with peak single antenna gain of 2.5dBi in 2.4GHz and 5.6dBi in 5GHz; built-in antennas are optimized for vertical wall or desk-mounted orientation of the AP
- Meets or exceeds the FCC/ISED, CE, IEC/EN standards
- Combine wireless and wired access in a single compact form factor
- Perfect for organizations with work-from-home or teleworker initiatives
- Built-in technology that resolves sticky client issues for Wi-Fi 6 and Wi-Fi 5 devices
- Lifetime manufacturer limited warranty
| Manufacturer # | R3V38A |
| Brand Name | Aruba |
| Connector, Port or Interface Type(s) | Three Ethernet ports |
| Data Transfer Rate (gbps) | 1.5 |
| Data Transfer Rate (mbps) | 1500 |
| Depth in Inches | 1.57 |
| Frequency (wireless) | Dual Band 2.4/5GHz |
| Gaming | Non Gaming |
| Height in Inches | 5.9 |
| Max. Data Transfer Rate (mbps) | 1500 - 1999 |
| Series or Collection | 503H |
| True Color | White |
| Weight (lbs.) | 0.64 |
| Width in Inches | 3.39 |
| Wireless Bands | Dual Band |
| Wireless Connectivity | 802.11 a/b/g/n/ac/ax |
Details
These economical Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing mobile, cloud and IoT requirements. With a wireless aggregate data rate of up to 1.5 Gbps and gigabit local wired ports, they deliver the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike. The Aruba 503H series APs are designed to optimize user experience by maximizing Wi-Fi efficiency and dramatically reducing airtime contention between clients. Features include Orthogonal frequency-division multiple access (OFDMA), and cellular optimization. With up to two spatial streams (2SS) and 80MHz channel bandwidth, the 503H series provides groundbreaking wireless capabilities for budget-conscious deployments
- This access point provides high performance and cost-effective Wi-Fi 6 (802.11ax) for hospitality, branch, and teleworker deployments
- With a wireless aggregate data rate of up to 1.5Gbps, delivers the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike
- Contains three Ethernet wired network ports (RJ45) with auto-sensing link speed (10/100/1000BASE-T) and MDI/MDX
- Dimensions: 5.9"H x 3.39"W x 1.57"D
- Maximum power consumption: 10W DC powered, 11.4W POE powered
- Two integrated semi-directional antennas for 2 x 2 MIMO with peak single antenna gain of 2.5dBi in 2.4GHz and 5.6dBi in 5GHz; built-in antennas are optimized for vertical wall or desk-mounted orientation of the AP
- Meets or exceeds the FCC/ISED, CE, IEC/EN standards
- Combine wireless and wired access in a single compact form factor
- Perfect for organizations with work-from-home or teleworker initiatives
- Built-in technology that resolves sticky client issues for Wi-Fi 6 and Wi-Fi 5 devices
- Lifetime manufacturer limited warranty
