Highlights
View Details- Simplify IT operations with managed Gigabit Ethernet rack mountable switch that provides entry level, reliable, and convenient wired access connectivity
- 12 10/100/1000BASE-T port model with 2 convenient built-in 1/10 GbE SFP port uplinks and up to 139W of Class 4 PoE
- Flexibility to manage and simplify configurations with Aruba Central, Aruba NetEdit, easy to use Web GUI, or industry standard CLI
Aruba 6100 12-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL679A#ABA)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
The Aruba CX 6100 Switch Series is a modern family of entry level access switches perfect for branch offices, mid-market enterprise, and SMB networks. Designed for reliable, simple, and secure access, the Aruba CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile, and cloud applications. Prepare your network for tomorrow's unpredictable demands with a powerful Aruba ASIC architecture and programmable AOS-CX operating system used across the Aruba CX portfolio to deliver a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 139W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12 port model is perfect for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the Aruba CX 6100 also simplifies ownership with no switch software licensing requirements.
- Simplify IT operations with managed Gigabit Ethernet rack mountable switch that provides entry level, reliable, and convenient wired access connectivity
- 12 10/100/1000BASE-T port model with 2 convenient built-in 1/10 GbE SFP port uplinks and up to 139W of Class 4 PoE
- Flexibility to manage and simplify configurations with Aruba Central, Aruba NetEdit, easy to use Web GUI, or industry standard CLI
- Throughput: 45.1 Mpps
- Dimensions: 1.73"H x 10"W x 10.04"D
- Power consumption: 16W idle, 21.9W without PoE, 170W with PoE
- Using Aruba AOS-CX operating system across Aruba CX switching platforms and deployment domains provides a simpler, more consistent operator experience
- Delivers Layer 2 capabilities with support static routing, ACLs, robust QoS, traffic prioritization, sFlow, and IPv6 support
- Simplifies ownership with no switch software licensing or subscriptions required
- Designed with Aruba ASICs that deliver very low latency, increased packet buffering, and adaptive power consumption
| Manufacturer # | JL679A#ABA |
| Brand Name | Aruba |
| Data Rate Performances | 10/100/1000Base-T |
| Data Transfer Rate | 10/100/1000 Mbps |
| Depth in Inches | 10.04 |
| Gaming | Non Gaming |
| Height in Inches | 1.73 |
| Input Voltage | 100-240 VAC |
| Jumbo Frame | 9220 Bytes |
| Lacp | Yes |
| Layer | 2 |
| Max. Data Transfer Rate (mbps) | 1000 - 1499 |
| Network Management Type | Managed Switch |
| Number of Ethernet Ports | 12 |
| Performance Class | Gigabit Ethernet |
| Port Mirroring | Yes |
| Power Supply | Fixed power supply (165W) |
| Power over Ethernet | Yes |
| Quality of Service | Yes |
| Snmp | v1, v2, v3 |
| Series or Collection | 6100 JL679A |
| Switch Form Factor | Rack Mountable |
| True Color | Black |
| Vlan Support | Yes |
| Warranty Information | Limited Lifetime Warranty |
| Weight (lbs.) | 6.13 |
| Width in Inches | 10 |
Details
The Aruba CX 6100 Switch Series is a modern family of entry level access switches perfect for branch offices, mid-market enterprise, and SMB networks. Designed for reliable, simple, and secure access, the Aruba CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile, and cloud applications. Prepare your network for tomorrow's unpredictable demands with a powerful Aruba ASIC architecture and programmable AOS-CX operating system used across the Aruba CX portfolio to deliver a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 139W of IEEE 802.3at Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless 12 port model is perfect for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the Aruba CX 6100 also simplifies ownership with no switch software licensing requirements.
- Simplify IT operations with managed Gigabit Ethernet rack mountable switch that provides entry level, reliable, and convenient wired access connectivity
- 12 10/100/1000BASE-T port model with 2 convenient built-in 1/10 GbE SFP port uplinks and up to 139W of Class 4 PoE
- Flexibility to manage and simplify configurations with Aruba Central, Aruba NetEdit, easy to use Web GUI, or industry standard CLI
- Throughput: 45.1 Mpps
- Dimensions: 1.73"H x 10"W x 10.04"D
- Power consumption: 16W idle, 21.9W without PoE, 170W with PoE
- Using Aruba AOS-CX operating system across Aruba CX switching platforms and deployment domains provides a simpler, more consistent operator experience
- Delivers Layer 2 capabilities with support static routing, ACLs, robust QoS, traffic prioritization, sFlow, and IPv6 support
- Simplifies ownership with no switch software licensing or subscriptions required
- Designed with Aruba ASICs that deliver very low latency, increased packet buffering, and adaptive power consumption
| Attribute Name | Attribute Value |
|---|
