Highlights
View Details- High-performance ruggedized Ethernet switch is great for connecting IoT, access points, and user devices in harsh environments.
- Features 4 x 100M/1G BaseT Class 6 PoE ports supporting up to 60W per port, 20 x 100M/1G BaseT Class 4 PoE ports supporting up to 30W per port, and 4 x 1G/10G SFP ports
- Switching capacity: up to 128Gbps; routing throughput: up to 95Mpps
Aruba CX 4100i 24-Port Gigabit Ethernet Unmanaged Switch, Black (JL818A#ABA)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
The Aruba CX 4100i switch series is a modern family of ruggedized Ethernet switches ideal for connecting IoT, access points, and user devices in harsh environments. Created for high performance, reliable, and access with enhanced security, the Aruba CX 4100i switches provide versatile deployment options for enterprise networks extending beyond carpeted areas to challenging outdoor and industrial spaces. Based on the programmable AOS-CX operating system used across the Aruba CX portfolio, this IP30 ruggedized series helps deliver a more consistent, more efficient operator experience. This Layer 2 series has convenient built-in high-speed uplinks, supports both 30W and 60W PoE, and is ready for deployment with fan less 12 port DIN mount and 24 port 1U rack mount models. With robust QoS, support for static routing, and IPv6, the Aruba CX 4100i also simplifies ownership with no switch software licensing requirements.
- High-performance ruggedized Ethernet switch is great for connecting IoT, access points, and user devices in harsh environments.
- Features 4 x 100M/1G BaseT Class 6 PoE ports supporting up to 60W per port, 20 x 100M/1G BaseT Class 4 PoE ports supporting up to 30W per port, and 4 x 1G/10G SFP ports
- Switching capacity: up to 128Gbps; routing throughput: up to 95Mpps
- Mounts to an EIA/TIA standard 19" telco rack (mounting brackets included with product)
- SNMPv1/v2c/v3 support provides read capability of industry-standard Management Information Base (MIB), and private extensions
- With robust QoS, support for static routing, and IPv6, it also simplifies ownership with no switch software licensing requirements
- Management flexibility with support for Aruba Central, easy-to-use Web GUI, CLI, and Aruba NetEdit
- Fixed internal power supply (300W); power consumption is 23W
- Versatile form factors deliver both 30W and 60W PoE to optimize IoT power
- Built-in high-speed 1/10GbE uplinks for demanding applications
- Robust protection for sub-station applications and high tolerances for railway rolling stock, signaling and telecommunications
- Secure and simple access for IoT and users with Aruba Dynamic Segmentation
- Management flexibility with support for Aruba Central, easy-to-use Web GUI, CLI, and Aruba NetEdit
- No switch software licensing required
- 5-year manufacturer limited warranty
| Manufacturer # | JL818A#ABA |
| Brand Name | Aruba |
| Data Rate Performances | 128 Gbps |
| Data Transfer Rate (gbps) | 128 |
| Depth in Inches | 12 |
| Full-duplex | Yes |
| Gaming | Non Gaming |
| Gigabit Ethernet Uplink | Yes |
| Height in Inches | 1.73 |
| Input Voltage | 100-240V |
| Jumbo Frame | 9220 Bytes |
| Lacp | Yes |
| Layer | 2 |
| Max. Data Transfer Rate (mbps) | More than 3000 |
| Network Management Type | Unmanaged Switch |
| Number of Ethernet Ports | 24 |
| Performance Class | Gigabit Ethernet |
| Port Mirroring | Yes |
| Power Supply | Internal power supply |
| Power over Ethernet | Yes |
| Quality of Service | Yes |
| Snmp | Yes |
| Series or Collection | CX 4100i |
| Stackable | Non-Stackable |
| Switch Form Factor | Rack Mountable |
| True Color | Black |
| Vlan Support | Yes |
| Warranty Information | 5 Year |
| Weight (lbs.) | 14.26 |
| Width in Inches | 17.5 |
Details
The Aruba CX 4100i switch series is a modern family of ruggedized Ethernet switches ideal for connecting IoT, access points, and user devices in harsh environments. Created for high performance, reliable, and access with enhanced security, the Aruba CX 4100i switches provide versatile deployment options for enterprise networks extending beyond carpeted areas to challenging outdoor and industrial spaces. Based on the programmable AOS-CX operating system used across the Aruba CX portfolio, this IP30 ruggedized series helps deliver a more consistent, more efficient operator experience. This Layer 2 series has convenient built-in high-speed uplinks, supports both 30W and 60W PoE, and is ready for deployment with fan less 12 port DIN mount and 24 port 1U rack mount models. With robust QoS, support for static routing, and IPv6, the Aruba CX 4100i also simplifies ownership with no switch software licensing requirements.
- High-performance ruggedized Ethernet switch is great for connecting IoT, access points, and user devices in harsh environments.
- Features 4 x 100M/1G BaseT Class 6 PoE ports supporting up to 60W per port, 20 x 100M/1G BaseT Class 4 PoE ports supporting up to 30W per port, and 4 x 1G/10G SFP ports
- Switching capacity: up to 128Gbps; routing throughput: up to 95Mpps
- Mounts to an EIA/TIA standard 19" telco rack (mounting brackets included with product)
- SNMPv1/v2c/v3 support provides read capability of industry-standard Management Information Base (MIB), and private extensions
- With robust QoS, support for static routing, and IPv6, it also simplifies ownership with no switch software licensing requirements
- Management flexibility with support for Aruba Central, easy-to-use Web GUI, CLI, and Aruba NetEdit
- Fixed internal power supply (300W); power consumption is 23W
- Versatile form factors deliver both 30W and 60W PoE to optimize IoT power
- Built-in high-speed 1/10GbE uplinks for demanding applications
- Robust protection for sub-station applications and high tolerances for railway rolling stock, signaling and telecommunications
- Secure and simple access for IoT and users with Aruba Dynamic Segmentation
- Management flexibility with support for Aruba Central, easy-to-use Web GUI, CLI, and Aruba NetEdit
- No switch software licensing required
- 5-year manufacturer limited warranty
| Attribute Name | Attribute Value |
|---|
