Highlights
View Details- High performance, smart-managed stackable switch designed for small and growing businesses, fast and easy set-up and security you can trust
- This model has 24 x RJ45 10/100/1000, 2 x SFP+ 10GbE, 2 x 10GBASE-T ports
- Use the Instant On mobile app, cloud-based web portal or the local web GU to quickly setup, monitor and manage the device
Aruba Instant On 1960 24-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, White (JL806A#ABA)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
Aruba Instant On 1960 Switch Series includes four 10GbE connections to connect to servers, network storage devices, or to other switches. Two connections of 10GBASE-T deliver 10GbE over copper Category 6a cabling for simple, affordable, high-bandwidth connections to a maximum distance of 100 meters. Each switch has a pull-out tag, known as a luggage tag, on the front panel of the switch. The tag includes a QR code that includes switch ID information (SKU number, SKU name, serial number, and MAC address) for easy switch onboarding through Instant On mobile app. The Aruba Instant On mobile app and cloud-based web portal make cloud-managed stacking easy — just follow the recommendations to stack up to four Aruba Instant On 1960 switches and manage as a single entity. The Aruba Instant On mobile app automatically detects members, making multiple stack members easy to setup and manage remotely. Automated configurations and streamlined workflows allow users to manage all stack members through one single dashboard without the need for device reboot. The Aruba Instant On 1960 Switch Series lets you use VLANs and Access Control Lists to set bounds on what data can be seen by which users. Leverage 802.1X with a RADIUS server to ensure only known and authorized users can access your network. Supports Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
- High performance, smart-managed stackable switch designed for small and growing businesses, fast and easy set-up and security you can trust
- This model has 24 x RJ45 10/100/1000, 2 x SFP+ 10GbE, 2 x 10GBASE-T ports
- Use the Instant On mobile app, cloud-based web portal or the local web GU to quickly setup, monitor and manage the device
- Throughput: 95 Mpps maximum; switching capacity: 128Gbps
- Dimensions: 1.73"H x 17.42"W x 13.8"D
- Power consumption at 100-127V: 60W maximum, 30W idle
- Powered by single core ARMv7 Cortex-A9 800MHz CPU
- Lifetime manufacturer limited warranty
| Manufacturer # | JL806A#ABA |
| Address Database Size | 16000 |
| Auto-sensing | Yes |
| Brand Name | Aruba |
| Data Transfer Rate | 10/100/1000 Mbps |
| Depth in Inches | 13.8 |
| Full-duplex | Yes |
| Gaming | Non Gaming |
| Height in Inches | 1.73 |
| Input Voltage | 100-240V |
| Jumbo Frame | 9216 Bytes |
| Lacp | Yes |
| Layer | 2 |
| Max. Data Transfer Rate (mbps) | 1000 - 1499 |
| Module Support | No |
| Network Management Type | Managed Switch |
| Number of Ethernet Ports | 24 |
| Performance Class | Gigabit Ethernet |
| Port Mirroring | Yes |
| Power Supply | Internal power supply |
| Power over Ethernet | No |
| Quality of Service | Yes |
| Snmp | v1, v2c, v3 |
| Series or Collection | Instant On 1960 |
| Stackable | Stackable |
| Switch Form Factor | Desktop, Wall Mountable, Rack-Mountable |
| True Color | White |
| Vlan Support | Yes |
| Warranty Information | Limited Lifetime Warranty |
| Weight (lbs.) | 8.7 |
| Width in Inches | 17.42 |
Details
Aruba Instant On 1960 Switch Series includes four 10GbE connections to connect to servers, network storage devices, or to other switches. Two connections of 10GBASE-T deliver 10GbE over copper Category 6a cabling for simple, affordable, high-bandwidth connections to a maximum distance of 100 meters. Each switch has a pull-out tag, known as a luggage tag, on the front panel of the switch. The tag includes a QR code that includes switch ID information (SKU number, SKU name, serial number, and MAC address) for easy switch onboarding through Instant On mobile app. The Aruba Instant On mobile app and cloud-based web portal make cloud-managed stacking easy — just follow the recommendations to stack up to four Aruba Instant On 1960 switches and manage as a single entity. The Aruba Instant On mobile app automatically detects members, making multiple stack members easy to setup and manage remotely. Automated configurations and streamlined workflows allow users to manage all stack members through one single dashboard without the need for device reboot. The Aruba Instant On 1960 Switch Series lets you use VLANs and Access Control Lists to set bounds on what data can be seen by which users. Leverage 802.1X with a RADIUS server to ensure only known and authorized users can access your network. Supports Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
- High performance, smart-managed stackable switch designed for small and growing businesses, fast and easy set-up and security you can trust
- This model has 24 x RJ45 10/100/1000, 2 x SFP+ 10GbE, 2 x 10GBASE-T ports
- Use the Instant On mobile app, cloud-based web portal or the local web GU to quickly setup, monitor and manage the device
- Throughput: 95 Mpps maximum; switching capacity: 128Gbps
- Dimensions: 1.73"H x 17.42"W x 13.8"D
- Power consumption at 100-127V: 60W maximum, 30W idle
- Powered by single core ARMv7 Cortex-A9 800MHz CPU
- Lifetime manufacturer limited warranty
| Attribute Name | Attribute Value |
|---|
