Highlights
View Details- Managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse, and two DisplayPort monitors
- Dimensions: 1.73"H x 6.17"W x 13.19"D
- One USB keyboard and mouse controls two/four DisplayPort computers and share two USB peripherals
Aten CS1944DP 4-Port USB 3.0 4K DisplayPort Dual Display KVMP Switch
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
The ATEN CS1944DP desktop KVM switch helps organize your desktop. Especially when managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse and two DisplayPort monitors. Advanced video support provides a better-defined DisplayPort connection with video resolutions up to 4K (4096 x 2160 / 3840 x 2160 @ 60 Hz). Incorporating dual display capability, you are allowed to enjoy a wider screen and easily switch between two or four DisplayPort systems. In addition, featuring a built-in USB 3.1 Gen 1 hub, the CS1944DP delivers unprecedented data transfer rates up to 5 Gbps, allowing you to maximize multimedia operations. Engineered to meet the ever-increasing demand for dual display, ultra-fast data transmission rates, and lossless 4K video resolution, the CS1944DP is specifically designed for where multitasking is needed such as design, financial trading, and video post production.
- Managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse, and two DisplayPort monitors
- Dimensions: 1.73"H x 6.17"W x 13.19"D
- One USB keyboard and mouse controls two/four DisplayPort computers and share two USB peripherals
- Supports quad displays by connecting two dual-display KVM switches
- Supports superior video quality: up to 4K (4096 x 2160/3840 x 2160 at 60Hz)
- Computer Selection via front panel, hotkeys, mouse, and RS-232 commands
- Two-port USB 3.1 Gen 1 hub with SuperSpeed 5Gbps data transfer rates
- Supports dual-mode DisplayPort technology (DP++)
- Supports MST (Multi-Stream Transport)
- Supports console keyboard emulation/bypass feature
- Supports console mouse emulation/bypass feature
- Independent switching of KVM, USB, and Audio
- Multilingual keyboard mapping: supports English, French, Japanese, and German keyboards
- DisplayPort 1.2 and HDCP compliant; supports HD audio
- Power on detection; firmware-upgradable
- Black
| Manufacturer # | CS1944DP |
| # of Ports | 20 |
| Brand Name | Aten |
| Connector, Port or Interface Type(s) | USB 3.1, DisplayPort, 3.5mm |
| Display Port | Yes |
| Kvm Cable or Switch Type | KVM Switch |
| Maximum Resolution | 4096 x 2160 |
| Number of Monitors | 2 |
| Os Compatibility | Computers |
| Usb | Yes |
Details
The ATEN CS1944DP desktop KVM switch helps organize your desktop. Especially when managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse and two DisplayPort monitors. Advanced video support provides a better-defined DisplayPort connection with video resolutions up to 4K (4096 x 2160 / 3840 x 2160 @ 60 Hz). Incorporating dual display capability, you are allowed to enjoy a wider screen and easily switch between two or four DisplayPort systems. In addition, featuring a built-in USB 3.1 Gen 1 hub, the CS1944DP delivers unprecedented data transfer rates up to 5 Gbps, allowing you to maximize multimedia operations. Engineered to meet the ever-increasing demand for dual display, ultra-fast data transmission rates, and lossless 4K video resolution, the CS1944DP is specifically designed for where multitasking is needed such as design, financial trading, and video post production.
- Managing a multimedia workstation at a large organization, CS1944DP provides you with instant access to two or four computers, all through a single USB keyboard, USB mouse, and two DisplayPort monitors
- Dimensions: 1.73"H x 6.17"W x 13.19"D
- One USB keyboard and mouse controls two/four DisplayPort computers and share two USB peripherals
- Supports quad displays by connecting two dual-display KVM switches
- Supports superior video quality: up to 4K (4096 x 2160/3840 x 2160 at 60Hz)
- Computer Selection via front panel, hotkeys, mouse, and RS-232 commands
- Two-port USB 3.1 Gen 1 hub with SuperSpeed 5Gbps data transfer rates
- Supports dual-mode DisplayPort technology (DP++)
- Supports MST (Multi-Stream Transport)
- Supports console keyboard emulation/bypass feature
- Supports console mouse emulation/bypass feature
- Independent switching of KVM, USB, and Audio
- Multilingual keyboard mapping: supports English, French, Japanese, and German keyboards
- DisplayPort 1.2 and HDCP compliant; supports HD audio
- Power on detection; firmware-upgradable
- Black
