Highlights
View Details- Four-channel video encoder that adds the benefits of IP surveillance to any analog camera system
- Encoder features two-way audio, I/O ports, and a memory card slot for edge storage
- Features 176 x 144/176 x 120 (PAL/NTSC) to 720 x 576/720 x 480 (PAL/NTSC); HDTVI, HDCVI, and analog HD (1280 x 720 and 1920 x 1080), single-channel 4K (3840 x 2160)
Axis P7304 Video Encoder, Gray (01680-001)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
AXIS P7304 is a full-featured, 4-channel video encoder that adds the benefits of IP surveillance to any analog camera system. It supports standard and HD analog cameras up to 4K resolution, and analog PTZ cameras. Enhanced security features such as signed firmware and secure boot ensure the integrity and authenticity of the encoder's firmware. Plus, Zipstream with support for H.264/H.265 video compression significantly reduces bandwidth and storage requirements. The encoder features two-way audio, I/O ports, and a memory card slot for edge storage. It also comes with intelligent analytics such as motion detection, audio detection and tampering alarm.
- Four-channel video encoder that adds the benefits of IP surveillance to any analog camera system
- Encoder features two-way audio, I/O ports, and a memory card slot for edge storage
- Features 176 x 144/176 x 120 (PAL/NTSC) to 720 x 576/720 x 480 (PAL/NTSC); HDTVI, HDCVI, and analog HD (1280 x 720 and 1920 x 1080), single-channel 4K (3840 x 2160)
- Four analog composite video BNC inputs, RJ45 10BASE-T/100BASE-T/1000BASE-T PoE, six-pin 2.5mm I/O terminal block with four configurable inputs and outputs
- Meets or exceeds EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35, IEC/EN/UL 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267 standards
- Features 25/30 fps in all resolutions up to 1080p, up to 30 fps in quad view in full-resolution 1080p, up to 15 fps in one-channel 4K
- ARTPEC-7 system on the chip with 1024MB RAM and 512MB flash memory
- Video compression: H.264 (MPEG-4 Part 10/AVC) Baseline, Main, and High profiles; H.265 (MPEG-H Part 2/HEVC) Main profile, Motion JPEG
- Image settings: compression, color, brightness, contrast, rotation (0/90/180/270 degrees), aspect ratio correction, mirroring of images, text and image overlay, privacy mask, enhanced deinterlace filter, video termination, anti-aliasing, sharpness, noise reduction, local enhancement
- Wide range of analog PTZ cameras supported, drivers included in the firmware; up to 100 preset camera positions, guard tour, PTZ control queue
- Audio encoding: 24-bit LPCM, AAC-LC 8/16/32/48kHz, G.711 PCM 8kHz, G.726 ADPCM 8kHz, Opus 8/16/48kHz, configurable bitrate
- Two analog or digital external microphone inputs or line input/output
- Network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
- Support for microSD/microSDHC/microSDXC card
- Support for recording to network-attached storage (NAS)
- Input voltage 8-28VDC; maximum wattage 8.2W
- Operating conditions: 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit), 10-85% RH humidity (noncondensing); storage conditions: -40 to 65 degrees Celsius (-40 to 149 degrees Fahrenheit), 5-95% RH humidity (noncondensing)
- Included accessories: installation guide, Windows decoder one-user license, DC input plug, six-pin I/O plug, two two-pin RS485/RS422 plugs
- 5-year manufacturer limited warranty
| Manufacturer # | 01680001 |
| # of Ports | 4 |
| Api | Open API for software integration, including VAPIX and AXIS Camera Application Platform |
| Brand Name | Axis Communications |
| Cpu | ARTPEC-7 |
| Dvi Output | No |
| Depth in Inches | 7.4 |
| Frame Rate (fps) | 30 |
| Height in Inches | 1.5 |
| Memory Type | Flash |
| Power Connector | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 |
| Resolution | 4K (3840x2160) |
| Series or Collection | P7304 |
| True Color | Gray |
| Video Capture Device Interface | Other |
| Video Capture Device Type | Video Encoders |
| Video Input Source(s) | BNC |
| Voltage-volts | 28 |
| Warranty Information | 5 Year |
| Watts | 8.2 |
| Weight (ounces) | 22.4 |
Details
AXIS P7304 is a full-featured, 4-channel video encoder that adds the benefits of IP surveillance to any analog camera system. It supports standard and HD analog cameras up to 4K resolution, and analog PTZ cameras. Enhanced security features such as signed firmware and secure boot ensure the integrity and authenticity of the encoder's firmware. Plus, Zipstream with support for H.264/H.265 video compression significantly reduces bandwidth and storage requirements. The encoder features two-way audio, I/O ports, and a memory card slot for edge storage. It also comes with intelligent analytics such as motion detection, audio detection and tampering alarm.
- Four-channel video encoder that adds the benefits of IP surveillance to any analog camera system
- Encoder features two-way audio, I/O ports, and a memory card slot for edge storage
- Features 176 x 144/176 x 120 (PAL/NTSC) to 720 x 576/720 x 480 (PAL/NTSC); HDTVI, HDCVI, and analog HD (1280 x 720 and 1920 x 1080), single-channel 4K (3840 x 2160)
- Four analog composite video BNC inputs, RJ45 10BASE-T/100BASE-T/1000BASE-T PoE, six-pin 2.5mm I/O terminal block with four configurable inputs and outputs
- Meets or exceeds EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35, IEC/EN/UL 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267 standards
- Features 25/30 fps in all resolutions up to 1080p, up to 30 fps in quad view in full-resolution 1080p, up to 15 fps in one-channel 4K
- ARTPEC-7 system on the chip with 1024MB RAM and 512MB flash memory
- Video compression: H.264 (MPEG-4 Part 10/AVC) Baseline, Main, and High profiles; H.265 (MPEG-H Part 2/HEVC) Main profile, Motion JPEG
- Image settings: compression, color, brightness, contrast, rotation (0/90/180/270 degrees), aspect ratio correction, mirroring of images, text and image overlay, privacy mask, enhanced deinterlace filter, video termination, anti-aliasing, sharpness, noise reduction, local enhancement
- Wide range of analog PTZ cameras supported, drivers included in the firmware; up to 100 preset camera positions, guard tour, PTZ control queue
- Audio encoding: 24-bit LPCM, AAC-LC 8/16/32/48kHz, G.711 PCM 8kHz, G.726 ADPCM 8kHz, Opus 8/16/48kHz, configurable bitrate
- Two analog or digital external microphone inputs or line input/output
- Network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTP/2, HTTPSa, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
- Support for microSD/microSDHC/microSDXC card
- Support for recording to network-attached storage (NAS)
- Input voltage 8-28VDC; maximum wattage 8.2W
- Operating conditions: 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit), 10-85% RH humidity (noncondensing); storage conditions: -40 to 65 degrees Celsius (-40 to 149 degrees Fahrenheit), 5-95% RH humidity (noncondensing)
- Included accessories: installation guide, Windows decoder one-user license, DC input plug, six-pin I/O plug, two two-pin RS485/RS422 plugs
- 5-year manufacturer limited warranty
