Fluke Networks Pro3000 Filtered Probe and Tone Generator Kit (PRO3000F60-KIT)

Signal interference from sources in the environment can make tracing cable a frustrating process. The Fluke Networks Pro3000 filtered probe blocks interference and "stops the buzz" by obstructing these signals allowing you to hear the tone you are tracing loud and clear. Probe's ergonomic sleek design is easy to handle and use. The large speaker on the probe makes the tone easier to hear through walls, enclosures, wood, or plaster. A recessed on/off button helps prevent the probe from accidentally being turned on in the pouch. Line cord features angled bed-of-nails clips and a rugged RJ11 plug for direct access to phone and data jacks without adapters. External switch allows selection of solid or alternating tone options, indicated with solid or flashing LEDs. Use the SmartTone capability of the Pro3000 analog tone generator to identify the right pair. When touching the wires together and momentarily shorting the far end of a cable pair, the SmartTone technology will change the cadence of the tone generated. This tone change you hear through the probe positively verifies the correct wire pair. SmartTone provides five distinct tones for exact pair identification up to 10 miles away.

• Filtered probe and tone generator kit for easy cable tracing
• Probe dimensions: 1.6"H x 9.8"W x 1.3"D; tone generator dimensions: 1.4"H x 2.7"W x 2.4"D
• Filtered probe comes in yellow and features a black replaceable tip; tone generator comes in blue
• Innovative filtered probe obstructs signal of 60Hz and its harmonic frequencies
• SmartTone technology provides five distinct tones for precise pair identification
• Sends loud tone up to 10 miles on most cables
• Slide switch selects continuity or tone mode
• Loud speaker on probe makes the tone easier to hear through drywall, wood, and other enclosures
• External switch allows for selection of solid or alternating tone options, indicated with solid or flashing LEDs
• Supports headset via 3.5mm audio port for use in noisy environments
• Angled bed-of-nails clips allow for easy access to individual pairs
• RJ11 connector is perfect for use on telephone jacks
• Supports switching between filtered and unfiltered modes with one button press
• Utilizes an auto-off feature that deactivates the probe after five minutes to conserve battery life
• Includes one spare tip
• Frequency modes: 1000Hz nominal solid frequency and 1000/1500Hz nominal alternating frequency
• Overvoltage protection: 60VDC in tone/polarity mode
• Output power in tone mode: 8dBm into 600 ohms
• Output voltage level in continuity mode: 8VDC with fresh battery
• Both probe and tone generator require a 9V alkaline battery
