Highlights
View Details- Plug-in card
- Dimensions: 4.6"(H) x 0.7"(W) x 4.7"(L)
- Interface/port: External ports: 1 x Fiber optic SC duplex female, Host interface: PCI-express x 1 Male
StarTech PCIe Gigabit Ethernet Adapter (PEX1000MMSC2)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
Startech.com® PCI Express gigabit Ethernet multimode SC fiber network card includes low profile and half height installation brackets for secure attachment. Network card is compatible with Windows 7/8/8.1/ XP/Vista, Linux and Mac OS.
- Plug-in card
- Dimensions: 4.6"(H) x 0.7"(W) x 4.7"(L)
- Interface/port: External ports: 1 x Fiber optic SC duplex female, Host interface: PCI-express x 1 Male
- Software requirement: OS compatibility: Windows 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), Windows Server 2012, 2008 R2, 2003, Mac OS 10.5 and up (tested up to 10.9), Linux 2.4.x/2.6.x/3.5.0, Microsoft Hyper-V
- Card type: Standard profile (LP bracket incl.)
- Data transfer rate: 2000 Mbps (2 Gbps) full-duplex, Buffer size: 48 KB
- Compatibility: PC, UART type: 16C550
- Network technology: 1000Base-X
- Compatible networks: 1000 Mbps, SC port type: Duplex
- Operating temperature range: 0 - 45 deg C, Storage temperature: -20 - 70 deg C, Humidity: 5 - 95% RH (non-condensing)
- LED indicators: 1 - link (green), 1 - activity (yellow)
- Power consumption: 3.2W Max
- Includes: 1 x port PCI-express gigabit fiber network card, 1 x Low profile bracket, 1 x Driver CD, 1 x Instruction manual
- Certification and standards:: RoHS, CE, FCC, IEEE standards: 802.3z, 802.1Q, 802.1P, 802.3x
- Weight: 2.3 lbs.
- Warranty: 2 years limited
| Manufacturer # | PEX1000MMSC2 |
| Brand Name | StarTech |
| Data Transfer Rate (gbps) | 2 |
| Data Transfer Rate (mbps) | 2000 |
| Depth in Inches | 4.7 |
| Gigabit | Yes |
| Height in Inches | 4.6 |
| Included Components | 1 x port PCI-express gigabit fiber network card, 1 x Low profile bracket, 1 x Driver CD, 1 x Instruction manual |
| Led Indicators | 1 - link (green), 1 - activity (yellow) |
| Max. Data Transfer Rate (mbps) | 2000 - 2499 |
| Network Adapter Interface | PCIe |
| Network Adapter Type | Ethernet |
| Selling Quantity | 1 |
| Selling Quantity (uom) | Each |
| Warranty Information | 2 Year |
| Weight (lbs.) | 2.3 |
| Width in Inches | 0.7 |
Details
Startech.com® PCI Express gigabit Ethernet multimode SC fiber network card includes low profile and half height installation brackets for secure attachment. Network card is compatible with Windows 7/8/8.1/ XP/Vista, Linux and Mac OS.
- Plug-in card
- Dimensions: 4.6"(H) x 0.7"(W) x 4.7"(L)
- Interface/port: External ports: 1 x Fiber optic SC duplex female, Host interface: PCI-express x 1 Male
- Software requirement: OS compatibility: Windows 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64), Windows Server 2012, 2008 R2, 2003, Mac OS 10.5 and up (tested up to 10.9), Linux 2.4.x/2.6.x/3.5.0, Microsoft Hyper-V
- Card type: Standard profile (LP bracket incl.)
- Data transfer rate: 2000 Mbps (2 Gbps) full-duplex, Buffer size: 48 KB
- Compatibility: PC, UART type: 16C550
- Network technology: 1000Base-X
- Compatible networks: 1000 Mbps, SC port type: Duplex
- Operating temperature range: 0 - 45 deg C, Storage temperature: -20 - 70 deg C, Humidity: 5 - 95% RH (non-condensing)
- LED indicators: 1 - link (green), 1 - activity (yellow)
- Power consumption: 3.2W Max
- Includes: 1 x port PCI-express gigabit fiber network card, 1 x Low profile bracket, 1 x Driver CD, 1 x Instruction manual
- Certification and standards:: RoHS, CE, FCC, IEEE standards: 802.3z, 802.1Q, 802.1P, 802.3x
- Weight: 2.3 lbs.
- Warranty: 2 years limited
