Highlights
View Details- Color: Black
- Number of ports: 2
- Console connectors: 1 x HDMI (19 pin) female, 2 x 3.5 mm mini jack (3 position) female, 4 x USB A (4 pin) female
StarTech SV231HDMIUA HDMI KVM Switch With Audio, 2 Ports
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
Connects devices from computers to audio and microphone switch.
- Color: Black
- Number of ports: 2
- Console connectors: 1 x HDMI (19 pin) female, 2 x 3.5 mm mini jack (3 position) female, 4 x USB A (4 pin) female
- Host connectors: 2 x HDMI (19 pin) female, 2 x USB B (4 pin) female, 4 x 3.5 mm mini jack (3 position) female
- Video resolution: 1920 x 1200 digital
- Port selection support: Push button and hotkeys
- Number of computers supported: 2, Enclosure type: Steel
- LED indicators: 2 X Online/active, green - connected PC is online, red - PC is selected
- Power: Voltage: 110 - 240 VAC (input), 12 VDC (output), Current: 0.8A (input), 1.5A (output)
- Center tip polarity: Positive, Plug type: M
- Graphic mode: WUXGA
- Audio, wide screen, OS independent, supports plug n play operation, audible tone to indicate PC switching, user defined scan time intervals, manual video adjustments via rear function button, eliminate duplicate
- Temperature: 0 - 40 deg C (operating), - 20 - 60 deg C (storage), Humidity: 80% RH
- System requirements: HDMI and USB enabled computer systems, HDMI enabled display device, standard 104 key wired USB keyboard, standard 3 button wired USB mouse
- Certification and standards: CE, FCC, ROHS
- Includes: 2 port HDMIKVM, package of rubber feet, power adapter, user manual
- Weight: 28.2 oz.
- Warranty: 3 years limited
| Manufacturer # | CN1868 |
| # of Ports | 2 |
| Brand Name | StarTech |
| Connector, Port Or Interface Type(s) | HDMI |
| Connects Devices (to and From) | Computers to audio and microphone switch |
| Hdmi | Yes |
| Included Components | 2 port HDMIKVM, package of rubber feet, power adapter, user manual |
| Kvm Cable Or Switch Type | KVM Switch |
| Maximum Resolution | 1920 x 1200 |
| Number of Computers Supported | 2 |
| Port Selection | Push button and hotkeys |
| System Requirements | HDMI and USB enabled computer systems, HDMI enabled display device, standard 104 key wired USB keyboard, standard 3 button wired USB mouse |
| Usb | Yes |
| Warranty Information | 3 Year |
Details
Connects devices from computers to audio and microphone switch.
- Color: Black
- Number of ports: 2
- Console connectors: 1 x HDMI (19 pin) female, 2 x 3.5 mm mini jack (3 position) female, 4 x USB A (4 pin) female
- Host connectors: 2 x HDMI (19 pin) female, 2 x USB B (4 pin) female, 4 x 3.5 mm mini jack (3 position) female
- Video resolution: 1920 x 1200 digital
- Port selection support: Push button and hotkeys
- Number of computers supported: 2, Enclosure type: Steel
- LED indicators: 2 X Online/active, green - connected PC is online, red - PC is selected
- Power: Voltage: 110 - 240 VAC (input), 12 VDC (output), Current: 0.8A (input), 1.5A (output)
- Center tip polarity: Positive, Plug type: M
- Graphic mode: WUXGA
- Audio, wide screen, OS independent, supports plug n play operation, audible tone to indicate PC switching, user defined scan time intervals, manual video adjustments via rear function button, eliminate duplicate
- Temperature: 0 - 40 deg C (operating), - 20 - 60 deg C (storage), Humidity: 80% RH
- System requirements: HDMI and USB enabled computer systems, HDMI enabled display device, standard 104 key wired USB keyboard, standard 3 button wired USB mouse
- Certification and standards: CE, FCC, ROHS
- Includes: 2 port HDMIKVM, package of rubber feet, power adapter, user manual
- Weight: 28.2 oz.
- Warranty: 3 years limited
