Highlights
View Details- 5 Gigabit Ethernet Ports provide high-speed data transfer rates of up to 1000 Mbps. This switch does not require any configuration and is easy to set up with plug-and-play functionality.
- Designed to be placed on a desk or other flat surface. Additionally, it can be wall-mounted if needed, providing flexibility in installation options.
- Has a switching capacity of 10 Gbps and a packet forwarding rate of 7.4 Mpps. This ensures efficient data transfer and high performance for connected devices.
TP-Link 5-Port Gigabit Ethernet Unmanaged Switch, 1000 Mbps, Gray (TL-SG105S)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
The TP-Link 5-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Plug and Play design, with no configuration required, makes the product easy to use. Moreover, the switch adopts lower power consumption design. With the innovative energy-efficient technology, it can save power consumption, making it an eco-friendly solution for your home or office network. Featured with 5 10/100/1000Mbps ports, it greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. You now have the choice to go green when upgrading to a gigabit network! This new generation 5-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
- 5 Gigabit Ethernet Ports provide high-speed data transfer rates of up to 1000 Mbps. This switch does not require any configuration and is easy to set up with plug-and-play functionality.
- Designed to be placed on a desk or other flat surface. Additionally, it can be wall-mounted if needed, providing flexibility in installation options.
- Has a switching capacity of 10 Gbps and a packet forwarding rate of 7.4 Mpps. This ensures efficient data transfer and high performance for connected devices.
- Automatically adjusts power consumption according to the link status and cable length, reducing power usage when ports are idle.
- Certified by: Restriction of Hazardous Substances (RoHS).
| Manufacturer # | TLSG105S |
| Address Database Size | 2000 |
| Auto-detecting | Yes |
| Auto-sensing | No |
| Brand Name | TP-LINK |
| Buffer Memory | 1MB |
| Data Rate Performances | 10/100/1000Base-T |
| Data Transfer Rate | 1000 |
| Data Transfer Rate (gbps) | 1 |
| Data Transfer Rate (mbps) | 1000 |
| Depth in Inches | 3.85 |
| Full-duplex | Yes |
| Gaming | Non Gaming |
| Height in Inches | 0.98 |
| Input Voltage | 5v |
| Jumbo Frame | 16KB |
| Lacp | No |
| Layer | 2 |
| Max. Data Transfer Rate (mbps) | 1000 - 1499 |
| Module Support | Twisted Pair |
| Network Management Type | Unmanaged Switch |
| Number of Ethernet Ports | 5 |
| Output Voltage | 5v |
| Performance Class | Gigabit Ethernet |
| Power Supply | uses an external power adapter |
| Power over Ethernet | No |
| Protocols | IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p |
| Quality of Service | No |
| Stackable | Non-Stackable |
| Switch Form Factor | Desktop, Wall Mountable |
| True Color | Gray |
| Vlan Support | No |
| Warranty Information | Limited Lifetime Warranty |
| Width in Inches | 3.93 |
| Wireless Connectivity | No |
Details
The TP-Link 5-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Plug and Play design, with no configuration required, makes the product easy to use. Moreover, the switch adopts lower power consumption design. With the innovative energy-efficient technology, it can save power consumption, making it an eco-friendly solution for your home or office network. Featured with 5 10/100/1000Mbps ports, it greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. You now have the choice to go green when upgrading to a gigabit network! This new generation 5-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
- 5 Gigabit Ethernet Ports provide high-speed data transfer rates of up to 1000 Mbps. This switch does not require any configuration and is easy to set up with plug-and-play functionality.
- Designed to be placed on a desk or other flat surface. Additionally, it can be wall-mounted if needed, providing flexibility in installation options.
- Has a switching capacity of 10 Gbps and a packet forwarding rate of 7.4 Mpps. This ensures efficient data transfer and high performance for connected devices.
- Automatically adjusts power consumption according to the link status and cable length, reducing power usage when ports are idle.
- Certified by: Restriction of Hazardous Substances (RoHS).
| Attribute Name | Attribute Value |
|---|
