Highlights

View Details
  • Featuring five Gigabit Ethernet ports, the unmanaged switch belongs to the Gigabit performance class.
  • Data transfer rate of up to 1000 Mbps (1 Gbps) per port.
  • It has a desktop form factor and can also be wall-mounted.

TP-Link Omada 5-Port Gigabit Unmanaged Desktop Switch, 1000 Mbps, Black (DS105G)

Log in to see pricing

Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
Free Return
Online. Always free.
The TP-Link DS105G is a 5-port Gigabit Ethernet unmanaged switch designed for high-speed networking. It features plug-and-play installation, QoS for smooth traffic, and a durable metal casing, making it ideal for both home and office use. With support for up to 1000 Mbps per port, it ensures reliable and efficient data transfer.
  • Featuring five Gigabit Ethernet ports, the unmanaged switch belongs to the Gigabit performance class.
  • Data transfer rate of up to 1000 Mbps (1 Gbps) per port.
  • It has a desktop form factor and can also be wall-mounted.
  • Supports Quality of Service (QoS), specifically 802.1p/DSCP QoS.
  • Includes basic security features such as 802.1p/DSCP QoS for traffic prioritization and IGMP Snooping for optimizing multimedia traffic.
  • With a throughput of 7.4 Mpps and a switching capacity of 10 Gbps, it operates in store-and-forward mode to ensure error-free data transmission by checking each packet for errors before forwarding.
  • With a maximum power consumption of 3.1 W, it incorporates Green Ethernet technology to reduce power usage based on connection status and cable length, making it an energy-efficient choice for your network.
  • Effectively increases available bandwidth on your network
  • Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 5 ports
  • With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
  • The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
  • Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • Certifications & Standards: CE, FCC, RoHS
Manufacturer # DS105G
Address Database Size 2000
Auto-detecting Yes
Auto-sensing Yes
Brand Name TP-LINK
Buffer Memory 1MB
Data Transfer Rate 1000 Mbps (1 Gbps)
Data Transfer Rate (gbps) 1
Data Transfer Rate (mbps) 1000
Depth in Inches 3.9
Full-duplex Yes
Gaming Non Gaming
Gigabit Ethernet Uplink No
Height in Inches 1
Input Voltage 5 V DC
Jumbo Frame 16KB
Lacp No
Layer 2
Max. Data Transfer Rate (mbps) 1000 - 1499
Module Support No
Network Management Type Unmanaged Switch
Number of Ethernet Ports 5
Performance Class Gigabit Ethernet
Port Mirroring No
Power Supply DC, Power Adapter
Power over Ethernet No
Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p
Quality of Service Yes
Snmp No
Series or Collection Omada
Stackable Non-Stackable
Switch Form Factor Desktop, Wall Mountable
True Color Black
Vlan Support No
Width in Inches 3.9
Details
The TP-Link DS105G is a 5-port Gigabit Ethernet unmanaged switch designed for high-speed networking. It features plug-and-play installation, QoS for smooth traffic, and a durable metal casing, making it ideal for both home and office use. With support for up to 1000 Mbps per port, it ensures reliable and efficient data transfer.
  • Featuring five Gigabit Ethernet ports, the unmanaged switch belongs to the Gigabit performance class.
  • Data transfer rate of up to 1000 Mbps (1 Gbps) per port.
  • It has a desktop form factor and can also be wall-mounted.
  • Supports Quality of Service (QoS), specifically 802.1p/DSCP QoS.
  • Includes basic security features such as 802.1p/DSCP QoS for traffic prioritization and IGMP Snooping for optimizing multimedia traffic.
  • With a throughput of 7.4 Mpps and a switching capacity of 10 Gbps, it operates in store-and-forward mode to ensure error-free data transmission by checking each packet for errors before forwarding.
  • With a maximum power consumption of 3.1 W, it incorporates Green Ethernet technology to reduce power usage based on connection status and cable length, making it an energy-efficient choice for your network.
  • Effectively increases available bandwidth on your network
  • Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 5 ports
  • With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
  • The unmanaged switch provides a quick, easy and cost-saving way to add wired networking to your home, office or small business; no intervention needed
  • Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • Certifications & Standards: CE, FCC, RoHS
Attribute Name Attribute Value
