View Details- Single phase IEC-320 C20 16 A 100 - 240 V input
- Input voltage: 100 - 240 V, frequency required: 50/60 Hz output
- Outlet connector: 12 IEC C13, 2 IEC-C19
Tripp Lite Single-Phase 100 - 240 V Basic Power Distribution Unit, 14-Outlet, 1U Rack Mount, Black (PDU12IEC)
Log in to see pricing
Same-day Shipping
This product usually ships and arrives up to 1 - 2 days
Tripp Lite Single phase basic power distribution unit can be 1U/0U vertical rack mounted. Unit has adjustable mounting brackets to offer easy installation.
- Single phase IEC-320 C20 16 A 100 - 240 V input
- Input voltage: 100 - 240 V, frequency required: 50/60 Hz output
- Outlet connector: 12 IEC C13, 2 IEC-C19
- Overload protection: 16 A
- 1U/0U vertical rack mount
- Package includes: PDU12IEC rackmount power strip, warranty information, instruction manual
- Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
- Back panel grounding lug
- Reversible housing; 4 1/4" depth
- Typical applications: Internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for distribution of UPS, generator or commercially derived AC power to protected equipment
- Weight: 3.2 lbs.
- Dimensions: 1 3/4"(H) x 17 1/2"(W) x 4 1/2"(D)
- limited lifetime mfr. warranty
| Manufacturer # | PDU12IEC |
| Brand Name | Tripp Lite |
| Depth in Inches | 4.5 |
| Height in Inches | 1.75 |
| Input Voltage | 100 - 240 V |
| Operating Temperature (celsius) | 0 - 40 deg C |
| Outlet Connectors | 12 IEC C13, 2 IEC-C19 |
| Outlet Count | 14 |
| Output Frequency | 50/60 Hz |
| Overload Protection | 16 A |
| Phase | Single-Phase |
| Power Distribution Unit Type | Basic |
| Rack Units | 1U |
| True Color | Black |
| Warranty Information | Limited Lifetime Warranty |
| Weight (lbs.) | 3.2 |
| Width in Inches | 17.5 |
Details
Tripp Lite Single phase basic power distribution unit can be 1U/0U vertical rack mounted. Unit has adjustable mounting brackets to offer easy installation.
- Single phase IEC-320 C20 16 A 100 - 240 V input
- Input voltage: 100 - 240 V, frequency required: 50/60 Hz output
- Outlet connector: 12 IEC C13, 2 IEC-C19
- Overload protection: 16 A
- 1U/0U vertical rack mount
- Package includes: PDU12IEC rackmount power strip, warranty information, instruction manual
- Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
- Back panel grounding lug
- Reversible housing; 4 1/4" depth
- Typical applications: Internetworking, PC systems, telecommunications, audio/video, security, sound reinforcement and more. Ideal for distribution of UPS, generator or commercially derived AC power to protected equipment
- Weight: 3.2 lbs.
- Dimensions: 1 3/4"(H) x 17 1/2"(W) x 4 1/2"(D)
- limited lifetime mfr. warranty
| Attribute Name | Attribute Value |
|---|
